Most project teams get built backwards. Preliminary designs, budgets and schedules get underway well before appropriate site professionals have been engaged and critical site and infrastructure information is known. Then, when the project is finally underway, the environment surrounding the project site is seen for the first time, geological factors that impact construction are unidentified or underestimated, or the actual engineering costs to build on the site are higher than allocated.
The above-ground / below-ground divide
Architects are responsible for designing the overall look and function of a building. It’s incredibly important work. But buildings don’t exist in a vacuum – they sit on the earth, they shed water onto adjacent properties, they tap into a municipal water main and tie into a sanitary sewer. None of those systems are the architect’s problem.
That’s where civil and geotechnical engineers come in. Their work is below grade and outside the building envelope, which is exactly why so many developers treat it as an afterthought. It’s not. That beautiful floor plan is irrelevant if the soil changes under the foundation, or if the site grading sends stormwater into a neighbor’s property, or if the municipal sewer main running directly in front of the property lacks the capacity to serve it.
The underground work dictates what the overground work can actually accomplish. Act accordingly.
The land surveyor comes first – full stop
Before any design professional can do anything meaningful, a licensed land surveyor has to establish what you’ve actually got to work with. Your current conditions, as defined by a topographic and boundary survey – not an overview of existing public records.
Because old deeds have errors. Municipal GIS data is anything but current. Easements that don’t show up in a title search can literally bisect the footprint of your building. And if your topographic baseline is wrong – if all the elevation data that your civil engineer is working from doesn’t actually represent existing conditions – then every single grading calculation, every drainage design, and every floor elevation being set by your architect is based on false information.
A topographic map doesn’t just show you legal lines, it shows you physical reality: slope, drainage patterns, existing structures, trees, utilities. That information needs to feed every single discipline on the team. Your civil engineer can’t accurately calculate earthwork volumes without it. Your architect should never be setting finished floor elevations without it. It’s not this annoying formality that you kinda half-ass to get through permitting – it’s the single most important part that everything else rests on.
Geotechnical investigation: the risk you can actually quantify
Soil borings may not sound exciting, but they are vital for every project that truly cannot withstand a foundation failure – both because it would be physically catastrophic and because the lawsuit alone would bankrupt you.
Geotechnical engineering knowledge is cheap, but ignorance is very expensive. It’s always cheaper to let someone else take the risks involved in finding out what’s below the surface, before you buy a set of plans. It is far less expensive to spend a few thousand on due diligence borings than to get into construction with unstable soil.
The engineer can tell from relatively simple borings whether bedrock might be a problem, whether there is undocumented fill, whether some soils on site are suitable for engineered fill, whether a proposed retention pond might flood neighboring parcels, whether an expensive basement can be built on the anticipated site, etc. Every one of these ‘surprises’ saves you real money because they are not surprises that get encountered half-way through construction.
High groundwater over long periods might send you on an expensive hunt for artesian wells. A shallow layer of organics and rotten wood could lead to spectacular settlement issues over the first few years after building completion. Both are common issues you want to know exist before you start construction.
Rock can become really expensive if it has to be blasted for foundations. Do you think that ‘knoll’ would look cool with a turret? Or are you going to cry when you find out what it costs to remove? Expansive clays can destroy even modest buildings and asphalt and require entire strip malls to be jackhammered out and rebuilt elsewhere.
Utility infrastructure: the invisible grid that controls your footprint
All development requires water, sewer, power, and very often natural gas. However, it’s not as easy as just ordering a service from the utility company to get it onsite.
Utilities design means knowing where municipal mains are, how much capacity they have, and what the connection standards are. The closest water main may be running near capacity, which means the developer pays to extend the main or upsize it. A sewer main might require a lift station if the system has little to no excess capacity. A power service may require a transformer pad and secondary distribution work if it doesn’t have enough capacity.
The easiest way to know about and plan for these issues before you’ve bought land or gone too far down the architectural rabbit hole is to partner with a civil engineering firm that knows the questions to ask. A civil engineer will pull the data on existing infrastructure, contact the municipal utilities, and raise the red flags early in the process.
This also involves the actual design of where those lines are physically routed across the property. This affects where buildings can go, where pavement can’t, and where you can design landscaping. This isn’t a decision that can be made after the architects are done. It’s a design process that needs to occur simultaneously.
Stormwater management isn’t just compliance – it shapes your buildable area
Modern stormwater rules say that once your site is developed, the volume of water leaving it during a storm can’t be any higher than it would have been when the site was natural. Simple enough, right? Except that to make that happen, up to 40% of your buildable land might disappear under basins or bioswales or permeable pavement systems or underground storage of some other kind.
Hydrology and stormwater design are site specific and call for detailed knowledge of existing drainage patterns, soil infiltration rates, tributary areas (the total area that drains to a particular point on your site), and the capacity of outfalls downstream. This kind of civil engineering figures out how much more water your project will push off your site and into a neighbor’s living room and designs features that will catch or store it.
What always surprises developers about these requirements? They take up a lot of room. Too much room for some projects to be viable if the positive yield of every inch of the property has already been imagined. For instance, the amount and rate of water that would run off your site during a five-year storm may necessitate a surface parking lot that’s a bioswale.
A detention basin won’t fit anywhere on your site. In a dense urban area, perhaps removing the parking lot will. Then it goes underground. A solution 10 times costlier than a pond.
Environmental Site Assessments – Phase I and Phase II – belong in this same early window. A Phase I ESA reviews historical records and site conditions for evidence of contamination. If it flags anything, a Phase II involves actual soil and groundwater sampling. Contamination found after a purchase is a liability the buyer owns. Contamination found before gives the buyer leverage or an exit.
Bring the contractor in before the design is done
It is often assumed that contractors should enter the project sequence after the design is finished – their work should start with the drawings being issued for a bid. This assumption, however, is costly.
Early contractor involvement (ECI) implies inviting a general contractor or construction manager to the pre-construction team while the design is still underway. Their job is not to impact the architecture – their job is to provide feedback on constructability in real-time and cost estimates based on actual market quotations.
A constructability review conducted by an experienced contractor will unveil details that look nice on paper but are complex or costly to construct. It will highlight materials prescribed by the design team that have long lead times or are scarcely available. It will discover sequencing conflicts – i.e. instances where the work of one contractor’s team must precede the other, and the current design bars this sequence.
Per the research by the Construction Industry Institute (CII), effective front-end planning can reduce total project costs by up to 10% and shorten project schedules by as much as 15%. This return on investment is expected from the issues identified in the drawing package, not in the field.
Navigating permits, entitlements, and zoning
Obtaining a site plan approval seldom is a one-time event. Instead, the process typically unfolds in a series of sequential events over the course of weeks or months. Zoning approval is first. If a variance or new zoning classification is needed, it may require a public hearing (newspaper notice and all) to give the local planning commission authority to grant your request. Environmental permits – wetlands, floodplain, endangered species, and water quality – come next. Then, utility connection permits. Finally, building permits.
Civil consultants and land-use attorneys play distinct roles in this process. Civil engineers prepare the technical submittals – grading plans, utility plans, stormwater calculations, and site plans – that regulatory agencies review. Land-use attorneys handle the legal and procedural side: presenting to planning commissions, negotiating conditions of approval, and managing appeals if needed.
Neither can fully substitute for the other. And neither works well if the technical work underlying the application is underdeveloped. Weak drawings invite requests for additional information that extend timelines by weeks or months.
Digital coordination: catching clashes before they reach the field
Building Information Modeling has revamped how multidisciplinary coordination is carried out. By putting civil, structural, and MEP disciplines together in a 3D model shared environment, system clashes will happen within the model, rather than in the field, where fixing them results in costly pauses.
The utility line conflicting with a structural footing. The mechanical duct passing through a beam. The site drainage pipe intersecting a proposed electrical conduit. These aren’t just hypotheticals – they’re standard occurrences on projects where disciplines produce separate 2D work and don’t start coordinating until late in the game. But with earlier BIM-based coordination, the costs are significantly lower because the fix turns out to be a drawing revision.
Getting the team assembled before the design starts
The sequencing argument is, therefore, this: every expert hired after design is substantially complete is adapting to a set of decisions about which they had no input because their hiring has not yet occurred. In other words, they are working in a constrained environment rather than an environment where they inform decisions. That is more expensive, and it produces a less good outcome.
The team that winnows a project down to budget and schedule is the team that was working together during feasibility, i.e., before the architectural concept was substantially locked, before the site was bought, before the scope was relatively well set. Get the surveyor on site. Order the borings. Engage the civil. Put your arm around a contractor and get cost feedback. Then let the architect design, with full knowledge of what is actually possible on the site.
